Product Detail

Stamping die parts

  • Metal stamping parts are components that are formed by pressing metal sheets into specific shapes using a press machine and molds.
  • Application: Automobile bodies, frames, fuel tanks, appliance shells, structural components of electronic devices, kitchenware, hardware accessories, etc.
  • It can be found in almost every industrial field.
    • Request An Inquiry

    The main feature of Stamping die parts:

    • During the pressing process, the surface of the material is not damaged, resulting in good surface quality.
    • The appearance is smooth and beautiful, which provides convenient conditions for surface painting, electroplating, phosphating and other surface treatments.
    • The pressing parts have high dimensional accuracy.
    • The dimensions of the same die are uniform and have good interchangeability.
    • They can meet general assembly and usage requirements without further mechanical processing.
    • The pressing parts are manufactured by pressing under the premise of consuming little material.
    • The parts are lightweight, have good rigidity, and the internal structure of the metal after plastic deformation improves the strength of the pressing parts.



    • The metal stamping parts steps: design preparation, stamping processing, post-processing and inspection packaging.
    • The specific steps may be adjusted according to the complexity of the product.
    Step Specification
    stage of preparation First, design the product drawings and determine the materials (such as stainless steel, aluminum alloy, etc.),

    Then cut the sheets to the appropriate size,

    And at the same time manufacture or debug the special molds.
    Processing of stamping die It mainly consists of two major processes:

    The separation process (such as blanking, punching, trimming, etc., which separates the material along the contour line)

    And the forming process (such as bending, deep drawing, flanging, bulging, etc., which causes the material to undergo plastic deformation without being damaged).

    Simple parts can use single-process dies, while complex curved surface parts require progressive dies or compound dies to form multiple processes at once.
    After treatment After the pressing process, remove burrs, clean and degrease,

    Then perform surface treatment according to requirements (such as polishing, electroplating, anodizing, sandblasting, etc.),

    Finally inspect the dimensional accuracy and appearance quality, and if qualified, pack and store in the warehouse.
