Shortcoming and limit:

  • Uneven contraction leads to deformation
  • Strength loss of the weld seam
  • Differences in environmental tolerance
  • Internal stress issue



The main process of injection molding stages:

Mold closing, filling, holding pressure, cooling, mold opening, and demolding.

Stage Description
Casting closure The mold is closed and locked to prevent material from overflowing during injection.
Filling The molten plastic is injected into the mold cavity at high speed until it fills approximately 95% of the cavity.
Pressure retention

(Holding pressure)

 Continuously apply pressure to compensate for shrinkage and ensure the integrity of the product dimensions.
Cooling The process of using a cooling medium to solidify and shape the plastic, which takes the longest time.
Mold opening The mold is opened, ready for the product to be ejected.
Demolding The ejection mechanism pushes the product out, completing the production cycle.



The advantage in production and economic:

High efficiency and automation Short forming cycle (usually 30-60 seconds), suitable for large-scale continuous production, low labor cost.
High initial investment The mold design and manufacturing process is lengthy and costly

(ranging from tens of thousands to several hundred thousand yuan),

And it is not suitable for small-batch or single-piece production.
Material utilization rate The waste from gates and channels can be recycled and reused, resulting in low raw material loss. However,

if the proportion of recycled materials is too high, it may affect the performance.
Defect sensitivity Extremely sensitive to process parameters (temperature, pressure, speed)

And mold design (uniform wall thickness, venting, cooling),

Prone to problems such as flash, shrinkage, bubbles, and stress cracking.
